Dr HDMI

£60.00

This Kit includes:

  • Dr HDMI Converter
  • 6′ USB>mini USB cable

9953 in stock

SKU: DR-HDMI Categories: , Tag:

Description

Dr HDMI can help to solve most HDMI issues such as handshaking issues, compatibility issues, and/or any EDID related issue. It helps to keep a source always ON or tricked into a defined state which is especially useful for system integrators.

Dr HDMI can also boost signal integrity and extend +5v signal through an HDMI/DVI-D chain.
For example, it can work hands in hands with HDfury products such as Gamer Edition to extend compatibility range.

It can also be used to limit the source output resolution.
Dr HDMI acts as an EDID manager, HDMI/DVI-D emulator, and repeater that comes with pre-defined presets, user programmable banks, Sink EDID sniffing bank, and more!

Highlight Features

  • Solve Most HDMI issues!
  • Fix HDMI handshaking issue
  • EDID Manager and Detective feature
  • Easy EDID table manipulation via USB port
  • HDMI/DVI-D emulator and repeater
  • Maintain 2K, 1920×1200, 1080p video without losing sync.
  • Predefined Banks (FullHD 3D, FullHD, 1080i, 720p, etc..)
  • User programmable EDID Banks
  • Sink EDID sniffing feature
  • Extend signal integrity up to 50 meters!
  • Can work standalone without any PSU connected (taking power from HDMI)
  • HDCP compliant

Technical Specs

  • HDMI 1.4a compliance
  • 8 EDID banks (5 pre-defined, 2 user programable, 1 copy from Sink device)
  • Reset HPD-event on the fly !
  • Up to 50 meters cable loss compensation
  • Keep source’s HDMI/DVI-D output active
  • USB upgradable and flashable from computer
  • User programmable EDID Banks
  • Sink EDID sniffing feature
  • Extand signal integrity up to 50 meters !
  • HDMI Pin14 on/off siwtch to fix HEAC/ARC compatibility issue
  • Any resolution including HDMI standards
  • Video Bandwidth : 2.25 Gbps
  • Video support: Single-link 225Mhz, 2k, WUXGA, 1080p60/12bit deep color and x.v.color
  • Audio support: Dolby True HD & DTS Master Audio
  • Input cable equalization
  • Support extended EDID CEA861, 256 byte
  • HDCP Pass-Through
  • Lip Sync Pass-Through
  • CEC Protocol Pass-Through
  • Power: Universal USB power adaptor
  • Compliance: HDCP/FCC/CE
  • Warranty: 1 year (extendable)
  • Dimension : 60mm W x 40mm D x 20mm H
  • Net weight : 50 gramms
  • Input/Output connector: HDMI female
  • USB: Mini USB-B female connector

Please check also the new dr hdmi 4k

For more information like drivers and software for the dr hdmi please go to this website www.drhdmi.eu
